7 DAY PROGRAMABLE (ATS) MAINS-GENERATOR
ATS / AMF Our control panels use the highest quality products and can be amended to your specification, and bespoke built to your requirements.
Please note additions' may require a larger enclosure.
STANDARD SPECIFICATION (TOP SPEC)
AC1 Rated Contactors or ACB's Mechanically and Electrically Interlocked.
Some ATS panel require a D.C power source to operate (12vdc or 24 vdc), this is usually fed from the generator starting battery. However if this is not possible a alternative power supply can be supplied.
ATS / AMF PANEL & HOW DOES IT WORK
ATS panels are used where the local mains supply is backed up by an appropriately rated Generating set, with a 2 wire start facility. The ATS panel monitors the local mains supply and will request the generator to start if this supply should fail. The ATS panel will then control the switching of the load from the local supply to the generator with a adjustable time delay pre set to 30s. On restoration of the local mains supply the ATS panel will monitor the Supply to ensure it is stable and then transfer the load from the generator back to the mains supply also with a adjustable mains restoration timer pre set to 10s. Once this time has elapsed the ATS panel will request the generator to stop.
There is also a 7 day programmable timer for auto starting testing.
If you have any additional requirements please contact one of our sales team.
